2026 Manitou Group TJ 65
Get in Touch
Description
2026 Manitou Group TJ 65
Enjoy the performance of the TJ 65 telescopic boom lift! This Manitou machine has all the features needed to secure your handling operations in height: 360 degree continuous rotation, negative jib rotation, front and rear wheel steering, and max offset of 57 ft 10 in. Featuring an all-terrain structure, the TJ 65 allows you to easily move on all types of soils, including rough terrain, uneven or muddy. Optimize your work at heights with our innovative telesopic mobile elevating work platforms.
Info
Industry
Agriculture
Make
Manitou Group
Model
TJ 65
Trim
Base
Year
2026
MSRP
N/A
Category
Telehandler
Subcategory
General
Specs
Height
8 ft 9 in | Working height: 71 ft 5 in | Platform height: 64 ft 10 in | Floor height (access): 1 ft 3 in | Overall height (stowed): 8 ft 11 in
Notes
Max. outreach: 57 ft 10 in | Pendular arm rotation (top / bottom): +69 ° / -66 ° | Platform capacity: 507 lb | Turret rotation: 360 ° | Platform rotation (right / left): 90 ° / 90 ° |Number of people (indoor): 2 | Platform dimensions (length x width): 6 ft 11 in x 2 ft 7 in | Counterweight offset (turret at 90°): 4 ft 5 in | Counterweight Oversize / Reach: 4 ft 5 in | Drive speed - stowed: 3 mph | Drive speed - raised: 0.62 mph | Gradeability: 40 % | Ground Pressure: 264 PSI | Hydraulic Pressure: 4931 PSI | Hydraulic tank capacity: 25 US gal | Vibration on hands/arms: < 2 ft/s²
Weight
Platform weight*: 26125 lb
Length
32 ft 2 in | Overall length (stowed): 23 ft 11 in | Jib length: 6 ft 7 in
Width
8 ft 2 in
Turning Radius
External turning radius: 20 ft 4 in
Ground Clearance
Ground clearance at centre of wheelbase: 1 ft 5 in
Wheelbase
9 ft 2 in
Tires
Solid tires | 40 x 14 in / 1025 x 365 mm
Wheels
Drive wheels (front / rear): 2 / 2 | Braking wheels (front / rear): 0 / 2
Steering
Steering wheels (front / rear): 2 / 0
Engine
Kubota - D1803-CR-TIE4B | Engine norm: Tier 4
Power/Horsepower
49.60 Hp / 37 kW
Fuel Capacity
19 US gal
