2026 Amazone 3200

2026 Amazone 3200

ZA-TS mounted spreader

High outputs with precise results
Highly efficient on a large scale – and yet precise right up to the field boundary. This is the only way to achieve professional fertilisation with high work rates whilst avoiding over-fertilisation and thereby protecting the environment at the same time. The ZA-TS and ZG-TS from AMAZONE meet these current fertilisation challenges with ease thanks to the innovative TS spreading system. Fertiliser is applied reliably, even in windy conditions, or when the fertiliser quality is poor. Up to 54 m working width, with hopper capacities of up to 10,000 litres, precise right up to the border. Pure precision from one spreading unit.
This is how the best in fertilisation works.

Product overview

Your benefits at a glance

High performance!

Highly efficient and intelligent
Precise spread patterns with working widths of up to 54 m and application rates of 650 kg/min

Precise!

AutoTS and BorderTS border spreading Systems
Proven precision, maximum yield at the field boundary

ProfisPro rate calibration
Absolutely accurate application rates from the very first second irrespective of the side

HeadlandControl headland optimisation
Uniform yield across the headland with optimised Section Control tailored to the shape of the spread fan

Intelligent!

WindControl
Windless conditions at the touch of a button to compensate for the effect of wind on the lateral Distribution

ArgusTwin
Permanent spread fan monitoring for optimum lateral Distribution under any conditions

The TS spreading system – Perfection in every component, just like clockwork

Characteristics of the TS spreading system

Delivery system adjustment of the TS spreading system

• Intelligent agitator for maximum fertiliser protection
• Electric setting motor for rotating the delivery system
• Delivery system for implementing the Section Control, HeadlandControl, WindControl, ArgusTwin functions
• Electric setting motor for precise fertiliser metering with application rates from 3 kg/min to 650 kg/min

Bottom assembly of the TS spreading system

• Electric setting motor for adjusting the carrier vane
• AutoTS gearbox, the heart of the integrated border spreading system
• Comfortable changeover between border and normal spreading by moving the carrier vane
• Short spreading vane for side, border and water course spreading
• Long normal spreading vane for high throwing widths and double overlap, even at a working width of 36 m

TS spreading disc

• TS spreading disc made of stainless steel, with easily exchangeable spreading vane sets TS 10, TS 20 and TS 30 for working widths from 15 to 54 m

Ultra-quick and precise! Electric actuators for the delivery system
The TS spreaders open up new dimensions in terms of maximum application rates, forward speeds and precision. To achieve this, they are equipped with an excellent delivery system with quick-reacting, precision actuators. Particularly in applications such as the automatic switch-on and switch-off at the headland or in wedge-shaped fields, spreading with application maps or via continuous on-board monitoring (ArgusTwin and WindControl), the delivery system guarantees the job is done at the highest level.

Concentric delivery point adjustment
The concentric rotation of the delivery system around the centre of the disc allows precise adjustment to various working widths and fertiliser types while protecting the fertiliser from shatter by placing it close to the centre of the spreading disc.

Quantity effect-free metering aperture
Due to the kidney-shaped design of the metering aperture, the spread pattern remains unchanged and precise, even at varying forward speeds and rates. This means that the position of the delivery system does not require constant adjustment.

The benefits of electric agitation

• two slow-running, fertiliser-protecting agitators; turning at just 60 rpm
• that switch off automatically as soon as the shutter slide is closed, also just to the one side and independently of each other
• that reverse automatically when blocked by a foreign object
• active delivery of the fertiliser flow to the aperture

The electric agitator with a brush unit ensures a continuous, precise fertiliser flow onto the spreading disc.

The TS spreading discs: For the utmost precision at all spreading widths up to 54 m

Spreading system made from stainless steel – For a long service life

On the TS spreaders, the entire spreading system is made from stainless steel providing a long service life.

The different spreading vane sets can be quickly and easily exchanged using an interchangeable system. The perfect solution, e.g. for agricultural contractors.

Between normal spreading and border spreading, different spreading vanes are activated via the so-called AutoTS system without the necessity to change spreading disc settings.

Hard-faced spreading vanes

The spreading vanes are coated with a special long-lasting anti-wear protection. Consequently, the result is a three-fold increase in lifespan.

Optimum working width ranges of the spreading vane sets, depending on the fertiliser being spread:

• TS 10 = 15 m – max. 27 m
• TS 20 = 21 m – max. 33 m
• TS 30 = 24 m – max. 54 m

ZA-TS – Fertiliser hopper in 1,400 to 5,000 litres

Advantages of the ZA-TS:

• Maximum precision during normal spreading and border spreading, regardless of external influences such as wind, hilly terrain or varying fertiliser properties
• Quick exchange of spreading vanes for flexible working widths
• User-friendly operation thanks to comprehensive software solutions for the spreader over and above the ISOBUS standard
• Precise fertilisation with high efficiency

Hopper extensions

For the ZA-TS, the following frames are available:

• Super frame: 3,200 kg payload, Cat. 2 linkage
• Ultra frame: 4,500 kg payload, Cat. 3 linkage

The benefits

• lightweight frame design with excellent rigidity
• optimised centre of gravity and yet plenty of space for hitching up

The best of both worlds - KTL cathodic dip-paint coating combined with powder coating

High-quality, multi-layer paint finish

The paintwork on a fertiliser spreader is exposed to particular demands. The paintwork is intended to protect the spreader from corrosion, especially when handling fertiliser and where moisture is involved. Starting with the 2022 model year, there is a new painting process for the ZA-V, ZA-TS and ZG-TS fertiliser spreader ranges. This involves, on the one hand, a cathodic dip painting process (known as KTL) for priming to give the best possible protection on the internal surfaces of tubes and box sections and, on the other hand, a powder coating process to create a high-quality visual finish with extra-thick paint providing increased protection against mechanical demands.

7 year manufacturer’s guarantee

Based on this optimum painting process, AMAZONE is able to offer its customers a manufacturer guarantee of seven years against rusting through, starting with the 2022 model year. From 01/01/2023, customers can apply to have the guarantee activated for ZA-V, ZA-TS, and ZG-TS models, starting from the 2022 model year. This registration is done very simply via the manufacturer’s portal, myAmazone, bearing in mind the terms and conditions (www.amazone.net/7-years) stated there. After registration, one can continue to work without any worries.

The benefits

• Cathodic dip painting process
  • Suppression of rust infiltration
  • Best possible protection, even on the inner surfaces of tubes and box sections
• Powder coated top coat
  • Double protection through additionally applied powder coating
  • Improved resistance against everyday wear and tear
• Quality and reliability
  • All the components on the spreading system and all hydraulic fittings are made from stainless steel
  • Impact, UV and chemical resistant plastic sieves

The combination of tried and tested painting techniques brings together the best from all areas, resulting in a high-quality, multi-layer paint finish

High-quality multi-layer paint finish – the most modern from all angles:

• 14-step paint preparation (e.g. degreasing)
• Zinc phosphating provides the most effective counteraction of rust formation
• Thick cathodic dip priming for full corrosion protection, even in cavities and those hard-to-reach areas
• Powder coating for a high-quality appearance and extra thick paint for increased protection against mechanical demands
