UF 02 mounted sprayer

The UF 02 mounted sprayer is available in tank capacities from 1,000 to 2,000 litres and with booms in working widths from 12 to 30 metres. The UF 02 is outstanding in its compact design, as well as its simple, comfortable operation. In combination with the FT front tank, the tank capacity of the highly manoeuvrable, tractor-mounted combination can be increased to 3,500 litres. That sets the standards! The AMAZONE UF 01 mounted sprayer is available in smaller boom widths of 12 to 24 m and tank capacities of 900 or 1,200 l.

Product overview

Your benefits at a glance

• Lifting force optimised design with a favourable centre of gravity mounting
• Ingenious quick coupling system and convenient parking aid for easy mounting and demounting
• SmartCenter: tailored operating systems – from the intuitively operated Standard-Pack to the Comfort-Pack with TwinTerminal 3.0
• High-performance 60 litre induction bowl and with a suction capacity of up to 150 l/min ensures the shortest possible fill times and homogeneous spray liquid mixing
• Outstanding, multi-facet spring suspension for a smooth boom ride
• DUS and DUS pro pressure recirculation systems for a continuous circulation of the spray liquid
• 50 cm part-width sections thanks to the AmaSwitch plus electric individual nozzle control
• Automatic cleaning programme for perfect cleaning results under all conditions

Exceptional performance

With its teamwork of shape and performance, the UF 2002 convinced and inspired the iF Jury, consisting of experts and designers from all over the world. The jury’s evaluation criteria included, in addition to the quality of design, the finish and material choice, the degree of innovation and the environmental compatibility, its functionality and ergonomics and, finally, a visualisation of use and safety.

Large volume spray agent tanks

The UF 02 mounted sprayer is available in tank capacities of 1,000 l, 1,300 l, 1,600 l and 2000 l. The specially shaped, polyethylene tank is integrated into the main frame to give a favourable centre of gravity. The advantages of this tank design are the absolutely smooth internal and external walls of the tank, the rounded internal design and the low positioned sump on the bottom of the tank. This allows for quick, effective tank cleaning as well as minimal residual volumes.

Filling of the tank is carried out, both when suction filling and also when pressurised filling, close to the bottom of the tank. This eliminates any tendency to foam during the filling procedure. For an intensive agitation capacity and to prevent any deposits settling in the tank, the agitator is also positioned down on the tank floor. The internal cleaning nozzle, the tank breather and the easily opened, domed lid are positioned right up in the tank.

Favourable centre of gravity – perfect frame design

Due to the large tank volumes of the UF 02, it is of importance to link the machine to the tractor with an as favourable a centre of gravity as possible. To ensure this, the UF 02 is equipped with two different link arm positions for different tractors. Guide plates in front of the frame help to link the lower link arms to the non-rotating, lower link pins.

Comfortable demounting – the parking system

The new parking system is completely integrated in the frame. As an option, the patented system can be equipped with castor wheels that remain on the machine even during operation. Via its simple and robust mechanical design, the parking stands or rollers can be quickly swivelled from the transport position up into the work position. Any troublesome removal of parking rollers or skids is avoided.

Comfortable hitching up – the quick coupling system

For an even more stress-free coupling and uncoupling of the UF 02, it can be equipped with the optional quick coupling system. In conjunction with the TeleSpace PTO shaft, or the hydraulic pump drive, the machine can easily be hitched on and off.

Stepless hydraulic main agitator

The intensity of the hydraulic agitator can, steplessly, be reduced down to nothing in order to avoid any foaming of the crop protection agent or to facilitate spraying out the remaining tank contents.

Everything thought of! Fill level and cleaning
The fill level can be read off both via a pointer or from the operator terminal. High-performance, rotating nozzles clean the spray agent tank internally. Short pipe runs and hose cross-sectional areas as small as possible make for low residual volumes. Continuous internal cleaning is available as an option (not with Flow Control+).

High-performance and reliable pump technology

The UF 02 can be equipped, from choice, with a single pump system that has a capacity of 150 l/min, 250 l/min or 300 l/min. During the filling procedure at a nominal pump speed, the full pump capacity is available for filling the spray agent tank. At the same time, either the contents of the induction bowl can be drawn out via the venturi or the total fill capacity can be increased up to 450 l/min.

Benefits of a piston diaphragm pump:

• Simple handling due to its self-priming capability at the start of the filling procedure
• Very high, consistent application rates with system pressures of up to 10 bar
• Can run dry and is liquid-fertiliser proof
• Long service life

Hydraulic pump drive

The UF 1602 and UF 2002 can be equipped with the new hydraulic pump drive as an option. The hydraulic pump drive is completely integrated in the load-sensing hydraulics of the sprayer and offers a comfortable and flexible option for driving the spray pump.

Advantages of the hydraulic pump drive:

• Pump drive independent of the tractor
• Protection of the pump due to no excessive speeds
• Easy coupling to and uncoupling from the tractor
• Fuel-efficient
• Maintenance-free

Centralised control – with the SmartCenter

The new SmartCenter operator station is equipped with a large hinged door that protects all the relevant operating controls and the induction bowl from dirt and water splashes. In the inner panel of the swing door, a holder for gloves and a measuring jug is provided. As the swing door opens backwards towards the boom, it protects the operator from chemical contact on his clothing from the booms plus, at the same time, creates plenty of free space between it and the tractor. With Standard-Pack, or the optional Comfort-Pack, AMAZONE offers two particularly comfortable solutions for the operation of the UF 02.

Well thought through – in every detail

The 20 l hand wash tank is positioned above the induction bowl and it is completely integrated into the machine design. The wash water runs directly into the induction bowl and is sucked into the tank. In addition, an easily accessible soap dispenser is positioned underneath the hand wash tank. The UF 02 comes as standard with a splash-proof clothing locker split into two with a capacity of 30 l in total for clean and contaminated protective clothing.

The benefits:

• Central layout of all relevant operating components; and all perfectly accessible
• Operator station, protected against dirt and splashes
• Splash-proof clothing locker with a capacity of 30 l
• Integrated hand wash tank with a tank volume of 20 l

Intuitive, simple, efficient – The right solution for any application

SmartCenter with Standard-Pack – simple and intuitive operation
The UF 02 is operated mainly using a suction and a pressure tap with the Standard Pack. The suction tap determines from where the pump is going to draw the liquid from, whereas, correspondingly, the pressure tap determines where the pump will send the spray liquid to. In addition, the in-house developed 7-way pressure tap from AMAZONE simplifies control of the pressure side.

SmartCenter with Comfort-Pack – Operation made easy

With Comfort-Pack, the TwinTerminal 3.0 comes as standard. Also, in addition, automatic fill stop for the suction fill is also included and, as an option, fill stop is also available when filling under pressure from a bowser. During application, the intensity of the agitation is regulated depending on the tank fill level. As the fill level decreases, the agitation capacity is automatically reduced down until it is completely switched off preventing the formation of foam at low tank volumes. In addition, the automatic agitation regulation offers auto-dynamic agitator control. This means: if larger application rates are required at the nozzle, the agitator output is reduced. When the nozzles are switched off on the headland, the agitation is automatically restored.

After the spraying operation is finished, Comfort-Pack provides fully automatic cleaning which can be controlled completely remotely from the tractor cab.

Additional functions such as boom rinsing, cleaning the spray liquid circuit from heavy deposits or a defined dilution of a subsequent tank mix in the field are all functions included within Comfort-Pack.

7-way pressure tap
The UF 02 is equipped with a 7-way pressure tap. As opposed to a normal rotary ball valve, the in-house developed valve from AMAZONE consists of a cam and valve seats. Exclusive: when swivelling in and out the pressure tap, the relevant route for the liquid is reliably opened or closed.

Exact mixing

Quick and safe with the induction bowl

Trouble-free filling with top performance
The 60 litre induction bowl is located directly below the operator controls. The phenomenal suction capacity of 150 l/min guarantees the quick, absolutely trouble-free filling and a complete emptying. For inducting powders or granular spray agents effectively, an additional mixing nozzle is positioned underneath the suction aperture which reliably prevents any blockage of the suction aperture. The mixing nozzle is infinitely-variable and can be operated in parallel to the infinitely adjustable output of the high-capacity rinse ring.

When suction or pressure filling, the induction bowl can be also supplied with fresh water using a steplessly adjustable 3-way valve!

The canister cleaning nozzle is activated simply by pushing down the canister or measuring jug. In the upper zone of the canister cleaning nozzle there is an additional, smaller contact area which is positioned where the nozzle can be activated, specifically for a more effective cleaning of the canister neck.

Details, such as the measuring jug holder and the drip tray for the canisters, located inside the dustproof and liquid-tight lid, provide the operator with an exceptionally pleasant operating environment. When the induction bowl is closed a complete internal cleaning can be carried out with the aid of the canister cleaning nozzle. The spray lance, included in the standard execution, is positioned to the right hand side of the induction bowl.

The benefits:

• Exceptionally quick, trouble-free filling
• Suction capacity of 150 l/min
• Fresh water supply during both suction and pressure filling
• Safe induction even of powder and granular spray agents, thanks to the additional mixing nozzle
• Practical folding measuring jug holder in the induction bowl lid
